Water Jump Pit Modular Forming Systems
- Sportsfield is the inventor and industry-leading provider of water jump pit forming systems
- Stay-in-place forming systems simplify installation and eliminate complex hand-forming
- Bolt-together aluminum construction with gusset reinforcement and watertight joints
- Prefabricated ninety-degree corner sections ensure accuracy and squareness
- Integrated drainage valve is conveniently opened and closed from ground level
- Modular aluminum cover sets ensure a safe condition when the pit is not in use
- Aluminum covers are recessed to accept synthetic track surfacing material
- Water jump and portable hurdles feature 1/2” synthetic track covered beams
- All components meet / exceed NFHS, NCAA, and IAAF specifications, rules, and requirements
- Custom cover sets and surface mounted water jump barriers available upon request
DESCRIPTION
Steeplechase Modular Water Jump Pit Forming System is designed to meet and/or exceed all NFHS, NCAA and IAAF specifications, rules and requirements. This dimensionally accurate system provides all the necessary features to create a safe, watertight and precise pit while eliminating the complex hand forming process associated with most cast-in-place structures.
DOCUMENTATION
SCWJFS50 - Steeplechase water jump pit forming system
| Title | Size | Date added | Download |
|---|---|---|---|
| SCWJFS50-CAD | 455.96 KB | 21-09-2023 | Download |
| SCWJFS50 Steeplechase Water Jump Pit Install Instructions | 1.88 MB | 21-09-2023 | Download |
| SCWJFS50 Steeplechase Water Jump Pit Forming System Cut Sheet | 1.05 MB | 21-09-2023 | Download |
| SCWJFS50 Steeplechase Water Jump Forming System and Components 3-Part Spec | 57.50 KB | 21-09-2023 | Download |
SCWJCVR - Steeplechase water jump pit forming system aluminum cover set
| Title | Size | Date added | Download |
|---|---|---|---|
| SCWJCVR Steeplechase Water Jump Pit Forming System Cover Set Cut Sheet | 732.15 KB | 21-09-2023 | Download |
| SCWJCVR - Steeplechase Water Jump Forming System Cover Set 3-Part Specification | 51.50 KB | 21-09-2023 | Download |
| SCWJCVR-CAD | 3.37 MB | 21-09-2023 | Download |
SCWJCVRCSTM - Custom steeplechase water jump pit aluminum cover set - ledge install
| Title | Size | Date added | Download |
|---|---|---|---|
| SCWJCVRCSTM Custom Steeplechase Water Jump Pit Cover Set Cut Sheet | 816.88 KB | 21-09-2023 | Download |
| SCWJCVRCSTM - Custom Steeplechase Water Jump Cover Set 3-Part Specification | 47.50 KB | 21-09-2023 | Download |
SCWJCVRCSTMH - Custom steeplechase water jump pit aluminum cover set - self-support / "hang"
| Title | Size | Date added | Download |
|---|---|---|---|
| SCWJCVRCSTMH Custom Steeplechase Water Jump Pit Hanging Cover Set Cut Sheet | 1.01 MB | 21-09-2023 | Download |
